4 Axle Flatbed Semi Trailer

4 Axle Flatbed Semi Trailer

13000 USD

The bottom plate of CIMC flatbed trailer for sale is a 3mm patterned plate, which is more durable and not easy to deform.

SKU: ZJV9501144
GTIN: 6975766106768
MPN: ZJV9501144
Brand: CIMC

4 Axle Flatbed Semi Trailer Price: 13000 USD

The beam of CIMC flatbed trailer for sale is made of low-carbon high-strength alloy Q345, which has stronger bearing capacity and a service life of more than ten years.

The beam of flatbed semi trailer is welded by automatic submerged arc welding process. There is no interface between the upper, middle and lower plates of the beam, which ensures the integrity of the beam and makes it more solid and durable. The top is 14mm thick and 140mm wide; the bottom is 16mm thick and 140mm wide; the middle height is 500mm high and 8mm thick.

4 Axle Flatbed Semi Trailer for Sale In Ghana

4 Axle Flatbed Semi Trailer for Sale In Ghana

4 Axle Flatbed Semi Trailer for Sale In Ghana

4 Axle Flatbed Semi Trailer for Sale In Ghana

4 Axle Flatbed Semi Trailer for Sale In Ghana

4 Axle Flatbed Semi Trailer for Sale In Ghana

4 Axle Flatbed Semi Trailer for Sale In Ghana

4 Axle Flatbed Semi Trailer for Sale In Ghana

4 Axle Flatbed Semi Trailer for Sale In Ghana

4 Axle Flatbed Semi Trailer for Sale In Ghana



Specification of Flatbed Semi Trailer

Dimension(mm): 13000x2500x1460mm

Loading capacity(ton): ≤80T

Axles: 4 axles, TITAN Brand

Tire: 16 units, 12R22.5

Suspension: Mechanical suspension

Landing gear: JOST

Brake system: WABCO



Advantages of Flatbed Semi Trailer

The gooseneck lower vertical plate of the CIMC flatbed trailer for sale beam is reinforced, and the deformation amplitude is very small when overloaded, which is more convenient to use

The gooseneck double-layer beam vertical plate of CIMC flatbed trailer for sale

All beams of CIMC flatbed trailer for sale are supported, and 6 channels are laid on the beams. The diagonal braces with a spacing of no more than 500 across the beams make it difficult for the vehicle to deform

CIMC flatbed trailer for sale uses polyurethane paint, which has high adhesion, high color rendering, beautiful color, and the cost is twice that of ordinary paint

CIMC flatbed trailer for sale The brake pads for sale are 220mm wide, which improves the braking performance and shortens the braking distance.

The bottom plate of CIMC flatbed trailer for sale is a 3mm patterned plate, which is more durable and not easy to deform.
