Tri Axle 60T Container Tipper Chassis Trailer

Tri Axle 60T Container Tipper Chassis Trailer Description:

Tri axle 60t container tipper chassis trailer adopts best quality tires. The quality is very stable.In China, it can use 200,000 kilometers for two years without any problem.

Tri axle 60t container tipper chassis trailer optional Jost landing gear which is a world recognized famous brand accessory with a better bearing capacity and long service life.

Tri Axle 60T Container Tipper Chassis Trailer for Sale with Best Prices Manufacturers

Tri Axle 60T Container Tipper Chassis Trailer for Sale with Best Prices Manufacturers

Tri Axle 60T Container Tipper Chassis Trailer Specification:

Dimension: 9300mmx2500mm x3700mm ( inside dimension )

Main beam: Height: 480mm, Upper plate: 14mm, Middle plate: 8mm, Lower plate: 14mm, Material: T700 steel.

Bottom Platform: 4 thick checkered plate

Side wall thickness: 4mm

Total volume: 60 Ton

End plate: 8mm

Lifting System: Full set of HYVA lifting cylinder

Axle: 13T/16T, FUWA / BPW / TITAN Brand

Rim: 8.0-20 or 9.00-20

Tire: 8.25R20/10.00R20/11.00R20/12R22.5

Suspension: Mechanical suspension

Spring leaf: 90(W)mmx13(Thickness)mmx10 layers

Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)

Landing gear: JOST brand

ABS: Optional

Valve: WABCO valve

Light: LED light (specially intended for oversea markets)

Voltage: 24V

Tool box: 1 set

Tri Axle 60T Container Tipper Chassis Trailer Advantages:

1. Hydraulic cylinder: The heavy-duty cylinder with a wider diameter, stronger lifting capacity and higher height, which makes the lifting more stable and does not easy to roll over.

2. Double-plate main beam for tipper semi trailer, which has a stronger carrying capacity, it is not easy to damage.

3. with 4 units vice beam and cross balance beam. The lattice structure of the side door makes the side door more solid.

4. The leaf spring is widened and thickened, the shock absorption effect is good.

5. Strengthened Ribs, unique structure design to maximize the payload.
