Brand:CIMC fuel tanker trailer
Dimensions:12500 mm(Length) x 2500 mm(Length) x3700mm(Height)
Tank Capacity:46800 liters
Tank Material:Aluminum alloy
Compartments:1 to 7 compartments, based on customer needs
CIMC aluminium fuel tanker designed intended for transportation of all fuel products. Aluminium fuel tanker preferred for its light weight during transportation of petroleum products.
The development of aluminum tanker trailer to light weight has improved the safety of vehicles, reduced the fuel performance, greatly enhanced the economic benefits for users, met the environmental protection and energy saving requirements of regulations, and is the development direction of international transportation vehicles.
1. Aluminum alloy fuel tank have good anti-corrosion performance, so as to ensure that the oil or chemical liquid is cleaner, and the volume is large and the weight is light.
2. The back protection material is high-strength steel ,the distance of which is large to prevent from drilling and collision in order to improve safety of vehicle.
3. The cross section of tank is international standard small circle arc so that the stress of tank is more uniform and stronger.
4. The dash board of head is of expansion structure ,high strength and the thickness of plate can meet international standard.
5. The loading and unloading system is designed according to European standard ,beng safe ,environmental friendly.
Overall dimension: 12500mm * 2500mm *3700mm
Application: Transport Fuel, Oil, Diesel
Material: Aluminum alloy
Axles: 3 axles, FUWA/BPW/CIMC/other
Suspension: Heavy duty mechanical suspension
Tire: 12 units
Compartments: 1 to 7 compartments, based on customer needs
King pin: 90#
Landing gear: JOST
Brake system: WABCO
Discharge valve: Diameter is 3 or 4 inch
