Product Type: Fuel dolly drawbar tanker trailers
Tank Capacity:20000 liters
Suspension: Mechanical suspension, Air suspension
Manhole Cover: Stainless steel manhole, diameter 500 mm
Bottom Valve: Stainless steel bottom valve
CIMC Full Drawbar Fuel Tanker Trailer Major parts and components of the trailer are processed by advanced equipment. Longitudinal beams are finished by automatic tracking submerged arc welding machine; all the sub-assemblies are shot-blasted to improve paint adhesiveness and are painted before assembling.
To ensure optimal structure for cargo handling and larger payload, the chassis is manufactured as a space frame structure of high-strength steel, 16Mn steel welded longitudinal beam and integrated cross member.
Our Axle of CIMC Full Drawbar Fuel Tanker Trailer adopt High performance domestic and imported axles with ABS system optionally available can significantly increase driving safety. High strength and impact resistance new type suspension is adopted with patented rod connecting design. It guarantees performance in rough road condition and longer service life.and with Large capacity water-proof detachable tool box.
CIMC Full Drawbar Fuel Tanker Trailer for Sale In Cote d'Ivoire ABIDJAN
Fuel Drawbar Full Tanker Trailer for Sale Price
Dimension: 9500mm*2500mm*3700mm(the exact size depends on the final design)
Volume: 20000liters
Application: transport Fuel, Oil, Diesel
Tank body:
Material: Carbon steel
Tank body and separate compartment plate: 6mm
Compartments: 1 to 7 compartments, based on customer needs
Manhole cover: Carton steel or Aluminum alloy API manhole cover 500mm (diameter)
Discharge valve: Diameter is 3 or 4 inch
Bottom valve: Aluminum API Pneumatic Bottom Valve
Tanker body test: Hydrostatic test to 5 psi (35 Kpa) on each compartment
Chassis:
Axles: 3 units, FUWA/BPW/CIMC/other
Landing Gear: JOST brand
King Pin: JOST brand 2.0 or 3.5inch(bolted or welded type)
Suspension: Mechanical suspension or air suspension
Brake System: WABCO
Tire: 12.00R22.5/315.80R22.5/11.00R20/12.00R20 brand can be optional
