Cement mixer trailer is optimization of body structure, special mold production, beautiful appearance, concrete mixing, discharge uniformity, low rate of residual.
3 axle cement mixer trailer for sale can feed, store, and discharge different types and grades of concrete to different construction projects. The capacity of trailer3 axle cement mixer trailer we can supply is from 3m3 to 16 m3. If customers have special requirements of volumes, we also can produce.
CIMC 3 Axle Cement Mixer Trailer for Sale In Nigeria
CIMC 3 Axle Cement Mixer Trailer for Sale In Nigeria
CIMC 3 Axle Cement Mixer Trailer for Sale In Nigeria
Main Dimensions
Overall Length: 10000mm
Overall Height: 3780mm
Overall Width: 2500 mm
Tare Weight: 12800 KGS
Tank
Capacity: 14 CBM
Mixing tanker sloping angle: 10-14 degree
Mixing tanker revolving speed: 12-20 (r/min)
Engine: Cummins diesel engine, 140 hp
Hydraulic pump: USA Eaton 6423-279 or Italian TOP brand
Hydraulic motor: Eaton 6433-042 or Italian TOP brand
Gearbox: Italy Bonfiglioli 580 L
Radiator Italian brand: YS26, 26 liters
Chassis
Axle: 3 axles ,BPW 13 Ton
Landing Gear: JOST brand Two-speed, manual operating, heavy-duty landing gear
King Pin: JOST brand 2” bolt-in king pin
Suspension: German design heavy duty mechanical suspension, 13-pcs leaf spring
Pneumatic Braking System: WABCO RE 4 relay valve; T30/30 Spring brake chamber; 40L air tanks.
Wheel rim: 9.00-22.5 wheel rim, 13 pcs
Tire: 12R22.5 tubeless tire, 13 pcs,
Painting: Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Accessories: One standard toolbox, one spare tire and carrier
