20ft Dump Trailer Chassis

Product Description：

CIMC Tipping Chassis semi trailers have many uses, and it can transport 20ft and 40ft containers. container dump trailers have 4 units flip brackets, which can make the rear end more evenly loaded during unloading, and it is not easy to damage the trailer.

CIMC dump chassis trailer can be customized according to customer special needs.

Different options: 2 axles, 3 axles, 4 axles, 20/40/45/53ft, 30T, 40T, 60T, airbag suspension, spring steel suspension; U-shape tip trailer, flatbed container tipper trailer, skeleton dumper trailer, side dump truck trailers.

3 axle heavy duty tipper chassis trailers

Specification：

Dimension: 6700x2500x2900mm

Loading Capacity: 40 ton

Transport: 20ft containers

Axles：3 axles(FUWA, BPW, CIMC, or Other Brand)

Tire：12 units

Twist Locks: 4,8,12 sets

Suspension：Mechanical suspension, Air suspension

Electrical System: 24-volt lighting system

King pin：50#, 90#

Landing gear：JOST

Brake system: WABCO

ABS: Optional

Light: LED light

Shipping Terms: Transported by the bulk carrier in a RORO or container
